SM-17 Sn.1059

Soilmec SM-17 is a multipurpose drilling rig developed from the fusion of TREVI GROUP job-site experience and SOILMEC technological research, thus perfectly responding to the needs of professionals worldwide.
Its modular design is engineered for the execution of: Micropiles, Tie-backs, Anchors, Jet Grouting and Mini-piles.

Standard Equipment

- Oscillating undercarriage
- Diesel power pack: 160 kW
- Heavy Duty mast 4.8 m stroke
- Cradle with side shifting
- Rotary head: 1400 daNm
- Clamping range 50-315 mm
- Full radio remote control

Optional Equipment

- Modular mast up to 10 m stroke
- Rotary head up to 3700 daNm
- Extractor device
- Rod loader 3x6 m - 3x10 m
- Jet Grouting Kit: 20 m
- Top Hammer Soilmec / Eurodrill /Krupp
- Double rotary head
- Foam pump
- Water/mud pump
- Service winch


SM-17 Sn.1059 | Soilmec Deutschland GmbH
SM-17 Sn.1059 | Soilmec Deutschland GmbH 2
SM-17 Sn.1059 | Soilmec Deutschland GmbH 3
Steuerbar per Funkfernbedienung
Technical data

Technical data

Engine kW 160
Weight t 18
Max hoist kN 100-120
